Next, enter ParametricBlockify and select the parametrized geometry. To use it, first parametrize the 2D or 3D geometry you want to use. Pretty handy!Ĭreate parametricly adjustable block destinations in 2D and 3D automatically with ParametricBlockify. It works in both 2D and 3D on single entities and collections of entities.įor example: if you add a length parametric constraint to a beam and then run the PARAMETRICBLOCKIFY command on the beam, BricsCAD will search the drawing for all versions of the beam that match, regardless of their length. ParametricBlockify not only detects similar geometry, but also identifies any geometry that matches its parametrically adjusted doppelgangers too. If you thought the BLOCKIFY command was cool, then you ain't seen nothin' yet. The Optimize Dialog will display a live preview of the entities in the dwg to be modified (dotted lines) so you can see how your settings will affect the drawing before you execute the command. No longer will you find entities with a length of 1.55739993348585712! Best of all? It does all this to the tolerance set by you.
It also closes gaps and rounds geometry to the nearest value. It recognizes lines that are not completely horizontal, vertical or on a 45° and it realigns them. Optimize automatically "tidies up" a drawing.
Distance tolerance bricscad how to#
If you've ever recived some dwg drawings from new intern, only discover that they don't know how to use snapping or otho, then OPTIMIZE is the command for you!Ĭlean up untidy and inaccurate dwg drawings without the manual labor with Optimize. OPTIMIZE corrects common drawing errors, without the need for manual editing. This reduces the size of your drawing and speeds up the drawing loading time.
It will then automatically assign all the blocks to a single block definition and delete the unused block definitions. Reduce the size of your drawings by automatically detecting and deleting redundant block definitions.įor example: if you have 5 different block definitions in the drawing, but they are all identical to each other in terms of size, shape and number of lines, BricsCAD will recognize this. You'll find it under the Ribbon under the Delete Duplicate Entities alias. It then deletes the redundant block definitions and intelligently reallocates them to the same block definition. This tool searches the drawing for any block definitions that are identical to any others. Max Deviation will set the variation from the existing polyline (how accurately you want BricsCAD to redraw the polyline).Īdding to the already powerful OVERKILL command, it's the delete duplicate Block definitions option. Simply put if two or more, segments are less than the maximum length and the difference in angle between them is less than the maximum angle, the two joining segments will be combined. Max Angle and Distance will set both the maximum distance between two points on a polyline and/or the maximum angle variation of two or more segments. SIMPLIFY comes in 2 options max Angle and Distance and max Deviation. SIMPLIFY reduces the number of vertices in polylines and hatch boundaries but still preserves the shape. Reduce the number of vertices in a polyline quickly and easily with Simplify.Įver look at a polyline and think "3,855 vertices! Why are there so many?" Or maybe you've spent all day redrawing lines because the number of vertices in a drawing is just ridiculous? Then you need SIMPLIFY! Optimize, simplify, parametricblockify, delete duplicate block definitions, and more! The new section contains both the new and old drawing optimization functions.ĭWG optimization Improvements for BricsCAD® Pro V21 include, but are not limited to. There is even a new section in the Ribbon for them. In this post, let's take a look at new dwg drawing optimization tools for BricsCAD ® V21.īricsCAD V21 brings you a whole host of new dwg drawing optimization tools.
Distance tolerance bricscad license#
